Printer Method |
Direct Line Thermal |
Print Speed |
37 Receipts Per Minute (180 mm/sec) |
Printer Case Color |
Putty or Gray |
Model Available |
TSP847 Includes Both Tear Bar and Auto Cutter |
Print Resolution (Vertical x Horizontal) |
203 (8 dots per mm) |
No. of Columns |
104mm Max with A4 Reduction Facility |
Font Size |
12 x 24 |
Character Matrix |
ANK, 12 x 24, IBM Graphic 12 x 32 |
Character Set |
ANK 95, 32 Int 128 Graphic |
Code Pages / Character Table |
40 Code Pages, Katakana, IBM |
Bar Codes |
9 versions |
Line Spacing |
3 mm or 4 mm or programmable |
Paper Specifications
Width
Thickness
Roll Diameter
Easy-Load
Paper Out Sensor
Black Mark Sensor
Paper Low Sensor
Maximum Print Width
|
112mm standard, Adjustable 82.5mm, 80mm, 58mm with Paper Guide 0.065 ~ 0.15 mm
Up to 100 mm
“Drop-In & Print”
Standard
Standard
Standard
104 mm Maximum |
Top Margin |
15 mm minimum default |
External Paper Feed Support |
Yes |
Auto Cutter |
Guillotine (Full or Partial Cut Selectable) |
Cover Open Sensor |
Yes |
Flash ROM / SRAM |
2 x 8 MBbit plus 2 x 1 Mbit Statis RAM |
Multiple Copy Support |
Supported through 2nd Copy Raster Driver |
Journal Capability |
N/A |
Label Support |
Yes; Black timing marks between labels required |
Power Supply |
External; Requires PS60A External Power Supply |
Drivers Available |
Windows 10, Windows 8.1, Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady 2009, OPOS™, JavaPOS™, USB Vendor Class, Linux™, Mac OS X, StarIO SDK with support for iOS and Android, and Scalable Raster Driver |
Digitally Signed (WHQL) |
N/A |
Swappable Interfaces |
Yes |
Connectivity |
WebPRNT Ethernet, WebPRNT Browser App, Apple MFi Certified Bluetooth, Serial, Parallel, USB, Ethernet |
Emulation Modes |
Star Mode, ESC/POS™ |
Peripheral Drive Circuit |
2 circuits, (24V max. 1A), 1 Compulsion input |
Power Consumption |
Average 1.8 Amp. Printing, 0.1 Amp. Standby
Requires PS60A External Power Supply |
Operating Conditions |
Temperature: 5ºC to 45ºC
Humidity: 10% – 90% RH (without condensation) |
Storage Conditions |
Temperature: -20ºC to 60ºC
Humidity: 10% – 90% RH |
Dimensions
Weight |
180 x 148x 213 (w x h x d)mm
1.7 kg |
Safety Standards |
UL, C-UL, TüV, CB, FCC, VCCI, EN55022, CE |
Reliability MCBF
Auto Cutter |
37 Million Lines
2 Million Cuts |
Included with Printer |
User Manual, Start Up Paper Roll, Ferrite Core |
Warranty |
2 Year Full Manufacturer Warranty |
Options |
External Power Supply (PS60A)
Kitchen Buzzer (BU01-24-A)
Vertical Stand (VS-T800)
Wall Mount Bracket (WB-T800)
Paper Guide (DIVIDER T800)
Swappable Interfaces
24V Mobile Power Supply
Swap-A-Star Extended Warranty Program (US)
Extend-A-Star Extended Warranty Program (US and Canada) |
